RUNWAY 16L/34R REMEDIATION WORKS AND THRESHOLD DISPLACEMENT AT HAMAD INTERNATIONAL AIRPORT (OTHH)

1 Introduction

The purpose of this AIP Supplement is to provide the phasing plan of the remediation works planned on RWY 16L/34R. Also, to inform all aircraft operators about the limitations due to this remediation works.

2 Phasing plan

The works are planned to proceed in 3 phases.

Phase 1 – Works are planned between TWY A and TWY A2.
During this phase RWY 16L/34R will be operated with reduced RWY length.

Phase 2 – Works are planned between TWY A8 and TWY A12.
During this phase RWY 16L/34R will be operated with reduced RWY length.

Phase 3 – During this phase RWY 16L/34R will be fully closed.

2.1 PHASE 1: 01-November-2025, 0000 UTC to 14-January-2026, 2359 UTC.

2.1.1 RUNWAY OPERATIONS:
Phase 1 – RWY 16L/34R will be operated as a non-precision RWY.

2.1.2 RUNWAY PHYSICAL CHARACTERISTICS:

RWY	Dimensions of RWY (m)	Threshold Displacement (m)	Strength (PCR) and surface of RWY	Threshold coordinates, RWY end coordinates	THR Elevation (ft)	Strip dimensions (m)	RESA dimensions (m)
1	2	3	4	5	6	7	8
16L	4270 x 60	NIL	851/F/A/W/T asphalt	251745.9659N 0513631.9578E 251537.1484N 0513728.7020E	13.21	4390 x 300	200 x 120
34R	4270 x 60	580	851/F/A/W/T asphalt	251537.1484N 0513728.7020E 251745.9659N 0513631.9578E	13.37	4390 x 300	200 x 120

2.1.3 DECLARED DISTANCES:
Phase 1 – RWY 34R THR will be displaced by 580m.

RWY	Intersection Departures	TORA (m)	TODA (m)	ASDA (m)	LDA (m)	Remarks
1	2	3	4	5	6	7
16L	Not Applicable	4270	4270	4270	4270	NIL
	TWY A11	4150	4150	4150	N/A
	TWY A10	3502	3502	3502	N/A
	TWY A6	1917	1917	1917	N/A
34R	Not Applicable	4270	4270	4270	4270	Threshold displaced by 580m
	TWY A3	3077	3077	3077	N/A	NIL
	TWY A6	2386	2386	2386	N/A	NIL

2.1.4 VISUAL AIDS – Markings:

RWY	RWY CL Markings	RWY Edge Markings	RWY TDZ Markings	RWY Designator Markings
1	2	3	4	5
16L	Available	Available	Available	Available
34R	Available	Available	Available	Available

2.1.5 VISUAL AIDS – Aerodrome Ground Lights:

RWY	APCH LGT	RWY THR ID LGT	THR LGT	THR WBAR LGT	PAPI	RWY CL LGT	RWY EDGE LGT	RWY TDZ LGT	RWY END LGT
1	2	3	4	5	6	7	8	9	10
16L	Available	Available	Available	Available	Available	Not Available	Available	Available	Available
34R	Not Available	Available	Available	Available	Port Side Available	Not Available	Available	Not Available	Available

2.1.6 CONSTRUCTION BOUNDARY AND EQUIPMENT HEIGHT:

LATITUDE	LONGITUDE	MAX HEIGHT (AGL)
1	2	3
251532.8167N	0513739.2466E	10m
251531.5552N	0513735.7821E
251530.4990N	0513735.2849E
251527.1360N	0513736.7656E
251527.9574N	0513739.0215E
251514.2781N	0513745.0444E
251510.9260N	0513735.8385E
251506.7148N	0513737.6928E
251506.5698N	0513737.2946E
251515.8018N	0513733.2298E
251514.3053N	0513729.1204E
251512.9895N	0513729.6997E
251513.9912N	0513732.4505E
251508.3345N	0513734.9411E
251506.9686N	0513731.1902E
251504.7604N	0513731.5534E
251504.7466N	0513731.1221E
251506.8196N	0513730.7811E
251512.4763N	0513728.2905E
251512.8204N	0513729.2353E
251514.1362N	0513728.6559E
251513.3332N	0513726.4581E
251512.7149N	0513725.8929E
251511.5341N	0513725.5356E
251510.2851N	0513722.1059E
251510.9173N	0513721.4387E
251511.8981N	0513724.1321E
251512.8701N	0513724.8657E
251514.0551N	0513726.0301E
251515.2211N	0513729.2320E
251526.4398N	0513724.2921E
251529.9934N	0513734.0475E
251530.9220N	0513734.6752E
251531.4277N	0513735.0279E
251531.8871N	0513735.6360E
251533.1485N	0513739.1005E

2.1.7 ASSOCIATED TAXIWAY CLOSURES:
Phase 1 – TWY A, TWY A1 and TWY B (between TWY A and TWY A2).

2.2 PHASE 2: 15-January-2026, 0000 UTC to 12-April-2026, 2359 UTC.

2.2.1 RUNWAY OPERATIONS:
Phase 2 – RWY 16L/34R will be operated as a non-precision RWY.

2.2.2 RUNWAY PHYSICAL CHARACTERISTICS:

RWY	Dimensions of RWY (m)	Threshold Displacement (m)	Strength (PCR) and surface of RWY	Threshold coordinates, RWY end coordinates	THR Elevation (ft)	Strip dimensions (m)	RESA dimensions (m)	CWY dimensions (m)
1	2	3	4	5	6	7	8	9
16L	3030 x 60	1820	851/F/A/W/T asphalt	251651.0612N 0513656.1477E 251519.6506N 0513736.4070E	13.34	3150 x 300	200 x 120	295 x 150
34R	3030 x 60	NIL	851/F/A/W/T asphalt	251519.6506N 0513736.4070E 251651.0612N 0513656.1477E	13.10	3150 x 300	200 x 120	NIL

2.2.3 DECLARED DISTANCES:
Phase 2 – RWY 16L THR will be displaced by 1820m.

RWY	Intersection Departures	TORA (m)	TODA (m)	ASDA (m)	LDA (m)	Remarks
1	2	3	4	5	6	7
16L	Not Applicable	3030	3325	3030	3030	Threshold displaced by 1820m
16L	TWY A6	2497	2792	2497	N/A	NIL
34R	Not Applicable	3030	3030	3030	3030	NIL
	TWY A1	2910	2910	2910	N/A
	TWY A2	2446	2446	2446	N/A
	TWY A3	1257	1257	1257	N/A
	TWY A6	566	566	566	N/A

2.2.4 VISUAL AIDS – Markings:

RWY	RWY CL Markings	RWY Edge Markings	RWY TDZ Markings	RWY Designator Markings
1	2	3	4	5
16L	Available	Available	Available	Available
34R	Available	Available	Available	Available

2.2.5 VISUAL AIDS – Aerodrome Ground Lights:

RWY	APCH LGT	RWY THR ID LGT	THR LGT	THR WBAR LGT	PAPI	RWY CL LGT	RWY EDGE LGT	RWY TDZ LGT	RWY END LGT
1	2	3	4	5	6	7	8	9	10
16L	Not Available	Available	Available	Available	Port Side Available	Not Available	Available	Not Available	Available
34R	Available	Available	Available	Available	Available	Not Available	Available	Not Available	Available

2.2.6 CONSTRUCTION BOUNDARY AND EQUIPMENT HEIGHT:

LATITUDE	LONGITUDE	MAX HEIGHT (AGL)
1	2	3
251657.8496N	0513649.7898E	10m
251701.8366N	0513646.1260E
251719.2480N	0513638.4554E
251718.0397N	0513635.1372E
251736.5298N	0513626.9905E
251736.4558N	0513626.7921E
251738.9569N	0513625.6900E
251742.5770N	0513624.0950E
251743.0322N	0513623.8944E
251742.1501N	0513621.4720E
251745.1494N	0513620.1504E
251746.3855N	0513619.6057E
251747.2272N	0513618.7618E
251747.3586N	0513617.5174E
251746.1124N	0513611.9750E
251745.8333N	0513611.0378E
251745.9649N	0513610.0622E
251746.1860N	0513609.4522E
251746.1818N	0513609.0967E
251745.9504N	0513608.8486E
251746.8855N	0513609.2598E
251746.4382N	0513610.4940E
251746.3823N	0513610.7638E
251746.4042N	0513611.0395E
251747.3077N	0513615.0578E
251748.1240N	0513617.2993E
251748.1037N	0513619.2143E
251746.8582N	0513620.5526E
251745.2065N	0513621.2804E
251747.1098N	0513626.5069E
251751.7706N	0513624.4532E
251755.2931N	0513634.1264E
251742.0248N	0513639.9725E
251741.2032N	0513637.7160E
251737.5362N	0513639.3316E
251737.0914N	0513639.8095E
251737.0826N	0513640.4941E
251738.3770N	0513644.0441E
251738.0452N	0513644.1903E
251736.9638N	0513641.2205E
251700.5678N	0513657.2544E

2.2.7 ASSOCIATED TAXIWAY CLOSURES:
Phase 2 – TWY A10, TWY A11, TWY A12, TWY C (between TWY A11 and TWY A12), TWY Q2 (between TWY B and TWY C) and TWY B (between TWY Q1 and TWY A12).

2.3 PHASE 3: 13 April 2026, 0000 UTC to 13 June 2026, 2359 UTC.

2.3.1 RUNWAY OPERATIONS:
Phase 3 – Full Runway Closure.

2.3.2 ASSOCIATED TAXIWAY CLOSURES:
Phase 3 – TWY A, TWY A1, TWY A2, TWY A3, TWY A4, TWY A5, TWY A6, TWY A7, TWY A8, TWY A9, TWY A10, TWY A11 and TWY A12.

3 Attachments

3.1 Graphical presentations of closures and work area boundaries are attached to this Supplement.

OTHH RUNWAY 16L/34R REMEDIATION WORKS (PHASE 1)

OTHH RUNWAY 16L/34R REMEDIATION WORKS (PHASE 2)

4 Updates

4.1 Operators are advised to monitor NOTAM and upcoming Supplements for updates.

-END-
