ESTABLISHMENT OF NEW TWY N1 AT DOHA INTERNATIONAL AIRPORT (OTBD)

1 INTRODUCTION

1.1 Establishment of TWY N1 at Doha International Airport for operational use.

2.1

Designation:

2.2

Width:

30M

2.3

Strength & Surface:

2.3.1	TWY N1 between edge of TWY Z and 106m from RWY 15-33 CL, Concrete, PCR 880/R/A/X/T.
2.3.2	TWY N1 between 106m from RWY 15-33 CL and Edge of RWY 15-33, Asphalt, PCR 1280/F/B/W/T.

2.4

TWY Center line lights:

Provided

2.5

TWY Edge lights:

Provided

2.6

Stop bar lights:

Provided

2.7

RWY Guard lights:

Provided

2.8

TWY CL marking:

Provided

2.9

TWY Edge line marking:

Provided

2.10

RWY Holding position marking:

Provided

2.11

Declared Distance for TWY N1 intersection:

2.11.1	RWY 33:	TORA 3034m	TODA 3217m	ASDA 3034m	LDA Not applicable
2.11.2	RWY 15:	TORA 1566m	TODA 1840m	ASDA 1566m	LDA Not applicable

3.1 A graphical representation of the taxiway is attached to this supplement.

New TWY N1

4.1 Valid UFN.

-END-
