Effective date: 13 JUL 2023|Publication date: 15 JUN 2023

AIRAC AIP SUP 09/2023

OBSTACLE BUILDINGS – DOHA INTERNATIONAL

1 INTRODUCTION

1.1 Permanent obstacle (buildings) are in the vicinity of Doha International airport which are neither depicted in any chart published by Qatar-AIM nor included in eTOD data still.

2 DESCRIPTION

2.1 Details of the obstacles are as follows:
Obstacle type*Obstacle position*HeightRemarks
1234

*Calculated data

Building251700.69N 0513225.17E -
251701.51N 0513225.16E -
251701.71N 0513227.14E -
251700.66N 0513227.10E -
251700.69N 0513225.17E.		73 m AGLBuilding is lighted with medium intensity obstacle lights type B or C.
Building251706.96N 0513335.37E -
251704.99N 0513335.72E -
251704.40N 0513334.22E -
251704.53N 0513332.01E -
251706.52N 0513331.80E -
251706.96N 0513335.37E.		47.65 m AMSLBuilding is lighted with medium intensity obstacle lights type B or C.
Communication Tower251542.71N 0513445.33E -
251542.67N 0513445.23E -
251542.76N 0513445.19E -
251542.80N 0513445.29E -
251542.71N 0513445.33E.		48.90 m AGLLighted with medium intensity obstacle light type B.

3 VALIDITY

3.1 Valid UFN.

4 REFERENCE

4.1 This supplement supersedes SUP 06/2023.
-END-
